Display Type

TFT active-matrix colour LCD

Size

7 in. (178 mm) diagonal

Aspect Ratio

16:10 WXGA

Resolution

1280 x 800 pixels

Brightness

350 nits (cd/m2)

Contrast

850:01:00

Colour Depth

24 bit, 16.7M colours

Illumination

Edge lit LED with auto brightness control

Viewing Angle

±80° horizontal, ±80° vertical

Touch Screen

Projected capacitive, 5-point multitouch capable

Buttons

Virtual Buttons

Virtual buttons in collapsible universal tool bar, per-button show/hide, pre configured with icons for Power, Home, Lights, Up, Down, and Microphone, optional custom programming via control system for additional functions.

Reset

Pin hole on bottom for hardware reset

Graphics Engine

HTML5 and Smart Graphics software technology, multilanguage web browser1, multilanguage onscreen keyboard, screensaver, single scalable streaming video window, native room scheduling applications4,5,6, native app1, native Zoom Rooms app7, native home OS app, setup.

Room Scheduling Support

Crestron Fusion

Software, Microsoft

Scheduling App

Compatible with Exchange Server and Office 365 software

Third-Party Apps

Includes support for various third-party scheduling applications.5,6

Languages

Memory

RAM

2 GB LPDDR3

Storage Firmware/Application:

16 GB eMMC pSLC

Maximum Project Size

600 MB

Wired Communications

Ethernet

100 Mbps, auto switching, auto negotiating, auto discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), IEEE 802.1X, SNMP, IPv4 or IPv6, Active Directory service authentication, HTTPS web browser setup, IEEE 802.3at compliant

Wireless Communications

Transceiver

IEEE 802.11a/b/g/n/ac Wi-Fi (2.4 or 5 GHz 2-way RF), static IP or dynamic IP via DHCР

Security

64 and 128-bit WEP, WPA and WPA2-PSK with TKIP and AES

Range

Up to 50 ft (15 m), subject to site-specific conditions

Streaming Decoder

Video Formats

H.265, H.264 (MPEG-4 part 10 AVC, MJPEG)

Audio Formats

AAC Stereo

Bitrates

Up to 25 Mbps (20 Mbps maximum recommended)

Input Resolutions

Up to 1920x1080 30fps Protocol RTSP

Audio

Features

Built-in microphone and speakers, Rava SIP Intercom, voice recognition1,2

Audio Feedback Formats

MP3

Connectors

LAN

PoE 8-pin RJ-45 connector, female, with 2 LED indicators 100BASE-TX Ethernet port; PoE+ PD port.

USB

USB Type A connector, female; USB 2.0 host port

Power

PoE (Power over Ethernet)

IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device); Requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power management; Requests 30 W (PoE+ Class 4) from an 802.3at Type 2 PSE without LLDP: Requests 15.4 W (PoE Class 0) from an 802.3af (or 802.3at Type 1) PSE

Warranty

3 Years

Ethernet

LEDs on RJ-45 connector

Power Pack

Input: 100-240VAC;
Output: 24VDC 2.5A

Power Consumption

14.8 W typical

Temperature

32° to 104° F (0° to 40° C)

Heat Dissipation

50.5 BTU/hr

Humidity

Transmitter: 20% to 90% RH (noncondensing);
Receiver: 10% to 90% RH (non-condensing)

Warranty

3 years

Power Pack

Input: 100-240VAC; Output: 24VDC 7.5A;

Temperature

32° to 104° F (0° to 40° C)

Humidity

Transmitter: 20% to 90% RH (noncondensing);
Receiver: 10% to 90% RH (non-condensing)

Warranty

3 Years
